Self-Adhesive Neodymium Disc Magnet - 15mm x 1.5mm | N35 | Single Magnet ONLY
Product code: 90004Sth
Prices are GST Incl.
Volume pricing available on requestAustralia's Leading Supplier
Shipping Worldwide*
30 Day Returns
Same Day Dispatch*
Magnetic Product Description:
This Rare Earth disc magnet (SINGLE MAGNET ONLY) has a diameter of 15mm and a height of 1.5mm. The magnet has a 3M 657 adhesive on one side of the magnet, the adhesive has a thickness of 0.06 mm. It is identified as AMF product code 90004Sth.
The discs are made from powerful Neodymium Magnets , with a pull force of 1.33 Kg, which makes them extremely strong for their size. The 3M adhesive backing negates the need for epoxy glue due to the reliable hold of the adhesive backing.
The magnets are NORTH poled on the non-adhesive side; and SOUTH poled on the adhesive side.
Permanent magnets come in a variety of forms and this term applies to many different types of hard form magnetic materials such as Neodymium, Ferrite and Samarium Cobalt. Neodymium is the most popular magnetic material in this day and age as it provides a superior super strong magnetic hold in comparison to traditional magnetic materials that pre-date it. Rare Earth disc magnets are certainly one of the most widely used products we sell as they are well suited to a huge array of applications. The low profile and wide surface area make them ideal for any job requiring an extremely strong hold that is resistant to shearing forces and sideways pressure
No FAQ available
NB: Ranges are indicative for product category, please check individual products for specic values within that range.
The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.
Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.
Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.
