Neodymium Disc Magnet - 6mm x 4mm

Product code: 20070

$1.04for 1 to 9 items
$0.84buy 10 to 99 itemsand save 19%
$0.69buy 100+ itemsand save 34%

Prices are GST Incl.

Volume pricing available on request

Neodymium Disc Magnet - 6mm x 4mm

Rated 4.8 out of 5
Based on 6 reviews
Product Code 20070
Pull Force* 1.25kg
Weight 1 gm
Style Rare Earth Disc magnet
Coating Nickel (NiCuNi)
Direction of Magnetisation Axially magnetised
Dimensions Height:4mm, Diameter:6mm

Magnetic Product Description:

This rare earth disc has a diameter of 6mm and a height of 4mm. It has a magnetic flux reading of 5318 Gauss and a pull force of 1.25kg. It is identified by the AMF magnet part number 20070.

Uses for our rare earth disc magnets:

This disc has a shape that lends itself to applications that require an ability to remove or reposition the magnet or the object it holds in place on a regular or scheduled basis. The thickness or profile of this disc allows it to be slid or pushed with the user's thumb or finger and by applying this sheer force or, in other words, a pressure at right angles to the magnetic orientation, the magnet can be moved. Thinner magnets do not provide this ability. This magnet is also popular for rebating into timber, gyprock or similar materials as they provide a good holding effect with little or no impact on the structural integrity of the material they are embedded in.

Neodymium Disc Magnet - 6mm x 4mm (20070)

Grade
N42 N/A
Max Operating Temperature °C
<=80 N/A
Remanence
1.3-1.35 N/A
Coercivity
13-13.5>=836 N/A
Intrinsic Coercivity
>=10.5 N/A
Max Energy Product
>=955 N/A
Grade N42
Max Operating Temperature °C <=80
Remanence 1.3-1.35
Coercivity 13-13.5>=836
Intrinsic Coercivity >=10.5
Max Energy Product >=955

NB: Ranges are indicative for product category, please check individual products for specic values within that range.

The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.

Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.

Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.

average rating 4.8 out of 5
Based on 6 reviews
  • 5 Stars
    5 Reviews
  • 4 Stars
    1 Review
  • 3 Stars
    0 Reviews
  • 2 Stars
    0 Reviews
  • 1 Star
    0 Reviews
100% of reviewers would recommend this product to a friend
6 Reviews
Reviewed by jimmy
I recommend this product
Rated 5 out of 5
Review posted

great magnets.. as in strength for the size

I machined some aluminium rod and inserted the magnets in to the end , producing a key fob magnet for testing ferrous and non ferrous metals.

Loading...
Was this helpful?
Reviewed by Hot D.
I recommend this product
Rated 5 out of 5
Review posted

Great product and service

Excellent, friendly and professional service. The magnets arrived on time and as ordered. They are very strong and performed as required.

Loading...
Was this helpful?
Reviewed by Peter
I recommend this product
Rated 4 out of 5
Review posted

Neodymium Disc - 6mm x 4mm

Delivered in good oredr and time, well and safely packaged.

Loading...
Was this helpful?
Reviewed by David
I recommend this product
Rated 5 out of 5
Review posted

Powerful little suckers

I was really impressed with the power in these compact magnets. Great company to deal with and speedy shipping.

Loading...
Was this helpful?
Reviewed by Richard H.
I recommend this product
Rated 5 out of 5
Review posted

Good delivery

Magnets where delivered as ordered and within the expected time, even though for Australia.

A work college has since ordered form AMF magnets for another R&D project we are working on.

Richard How, VAICO Engineer

Loading...
Was this helpful?
