Neodymium Disc - 20mm x 10mm

Product code: 20012

$16.74for 1 to 9 items
$14.36buy 10 to 99 itemsand save 14%
$13.06buy 100+ itemsand save 22%

Prices are GST Incl.

Volume pricing available on request

Neodymium Disc - 20mm x 10mm

Product Code 20012
Pull Force* 11 kg
Weight 23 gm
Style Rare Earth Disc magnet
Coating Nickel (NiCuNi)
Direction of Magnetisation Axially magnetised
Dimensions Height:10mm, Diameter:20mm
*Measured against up to 10mm mild steel.

Magnetic Product Description:

This rare earth disc has a diameter of 20mm and a height of 10mm. It has a magnetic flux reading of 4455 Gauss and a pull force of 11kg. It is identified by the AMF magnet part number 20012.

Uses for our rare earth disc magnets:

These compact and powerful Neodymium Discs are purchased by the Iron Ore producing companies of North and Western Australia. For such punishing work, steel fabrication and heavy-duty technologies are a necessity. These 20mmx10mm neodymium disc magnets, embedded in the mining tools and equipment, can be found all over the mine site. From helping out the rotary blast hole drill bits readying another section of rock for dynamiting, to the bulldozer mounted long wall boring attachment and the three storey driverless dump trucks, magnets mix with the toughest of machines, for the heaviest work, in the most demanding conditions.  Still operating at temperatures of up to 200 deg.C these magnets are known to generate an excellent cost to performance ratios and help prolong the lifespan and efficiency of incredibly expensive equipment. This in turn lowers production costs and keeps these companies profitable when Ore prices fluctuate.

Neodymium Disc - 20mm x 10mm (20012)

Grade
N38 N/A
Max Operating Temperature °C
<=80 N/A
Remanence
1.09-1.17 N/A
Coercivity
12.3-13>=859 N/A
Intrinsic Coercivity
>=10.8 N/A
Max Energy Product
>=955 N/A
Grade N38 N/A
Max Operating Temperature °C <=80 N/A
Remanence 1.09-1.17 N/A
Coercivity 12.3-13>=859 N/A
Intrinsic Coercivity >=10.8 N/A
Max Energy Product >=955 N/A
