Neodymium Cylinder Magnet - 4.76mm x 9.52mm | N50

Product code: C-D4.76H9.52-N50

$0.84for 1 to 9 items
$0.76buy 10 to 99 itemsand save 10%
$0.69buy 100+ itemsand save 17%

Prices are GST Incl.

Volume pricing available on request

Neodymium Cylinder Magnet - 4.76mm x 9.52mm | N50

Product Code C-D4.76H9.52-N50
Pull Force* 1.06 kg
Weight 1 gm
Style Neodymium Cylinder
Coating Nickel (Ni)
Direction of Magnetisation Axially
Dimensions Height:9.52mm, Diameter:4.76mm
*Measured against up to 10mm mild steel.

Magnetic Product Description:

This popular rare earth cylinder has a diameter of 4.76mm and a height of 9.52mm. It is an N50 grade rare earth magnet. It has a magnetic flux reading of 7031 Gauss and a pull force of 1.06kg.  It is identified by the AMF magnet part number C-D4.76H9.52-N50.

Uses for our rare earth cylinder magnets:

This Neodymium cylindrical magnet comes in the popular imperial measurements of 3/16 inch by 3/8 inch. These types of measurements are ideal for people working in imperial measurement or from an international based education who are more comfortable with this type of measurement.
Rare earth cylinders are commonplace components in all sorts of electronic devices and over time the magnet can corrode or be broken. We are often contacted by customers who have encountered these issues and are looking to locally source a replacement magnet without going to the expense or hassle of sourcing a single neo magnet from overseas. The quality of magnets found in mass produced products is often of a lower grade. The performance of the overall product can oftentimes be improved by simply replacing this with a stronger neodymium magnet of a higher grade and therefore stronger pull force.

Neodymium Cylinder Magnet - 4.76mm x 9.52mm | N50 (C-D4.76H9.52-N50)

Grade
N50 N/A
Max Operating Temperature °C
<=80 N/A
Remanence
1.4-1.46 N/A
Coercivity
14-14.6 >=836 N/A
Intrinsic Coercivity
>=10.5 N/A
Max Energy Product
>=875 N/A
Grade N50 N/A
Max Operating Temperature °C <=80 N/A
Remanence 1.4-1.46 N/A
Coercivity 14-14.6 >=836 N/A
Intrinsic Coercivity >=10.5 N/A
Max Energy Product >=875 N/A
