Product code: RCND43F
Leading Magnet Supplier
Shipping Worldwide*
30 Day Returns
Same Day Dispatch*
This rare earth female threaded pot magnet has a diameter of 43mm, a post height of 5mm, a base thickness of 5mm, a M4 female thread, and a Santoprene rubber coating that protects delicate surface areas. This female threaded magnet has a pull force of 9kg and a weight of 36 grams. It is identified by the AMF magnet part number RCND43F. Threaded hooks and eyelets are sold separately for this product, if required. Get in touch with us for pricing.
These Rubber Coated Holding magnets have a Female Thread and can provide simple and efficient storage and safety solutions at home, in the workplace, around the campsite or on the road. Attached to magnetic surfaces, on a vehicle, on metal shelving, inside mobile homes, demountable dwellings, commercial cool rooms and in many retail environments, these magnets create a permanent or temporary bond by attaching them to non-metallic items with a bolt. They can be used to attach safety barriers and protective screens to metallic door and window frames. Inside shipping containers, mobile homes and caravans, fragile items can be secured and stabilized without nails, screws or glue and without penetrating or damaging surfaces.
For truckers, campers and emergency services, these Holding Magnets provide a secure fixing point for temporary containment lines, signs and flashing lights while the rubber coating protects vehicle paint finishes.
No FAQ available
NB: Ranges are indicative for product category, please check individual products for specic values within that range.
The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.
Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.
Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.
The Pull Force listed for each magnet is based on lifting 10mm thick steel from a horizontal surface. Magnets on a vertical surface (of 10mm thick steel) are generally able to hold around only 30% of the pull force listed in the product description. This is due to the effects of gravity and the lack of friction between the surface and the shiny magnet. Read More
